• CW3962 Series

    • Poles: 2-14
    • Material: NYLON UL 94V-2
    • Contact: 1.14mm(.045") square pin. brass, tin plated 60u"
    • Mates with CH3962 series housing

    Specification

    • Current rating: 7A AC, DC
    • Voltage rating: 250V AC, DC
    • Temperature range: -25℃~+85℃
    • Insulation resistance: 1,000MΩ
    • Withstand voltage: 1,500V AC/minute
    • Applicable PC board thickness: .063"(1.6mm)

    CW3962

Order / Inquiry Information

Please select Items below and click See Catelog for Inquiry.
Part No. CW3962X
Poles
